Labelling Printers  AFS supply are own range of MLP printers along with Zebra, TSC, Intermec, Datamax, Honeywell & Toshiba  If you cant see the printer you are looking for please contact us directly and let our experts give you the advice you need.  Click Here For Free Advice and Costs

Zebra Labelling Printers

Zebra AFS GT800 Thermal Desktop Barcode Label Printer
Zebra GT800 Thermal Desktop Barcode Label Printer
GT800
• 300 meter ribbon capacity
• 32 bit RISC processor
• Co-resident EPL2 and ZPL II programming languages
• Triple connectivity: Serial, USB and parallel
• Print methods: Thermal transfer and direct thermal
modes; printing of bar codes, text and graphics.
• OpenACCESS™ for easy media and ribbon loading
• Microsoft® Windows® drivers
Printer Specifications
Resolution
203 dpi/8 dots per mm
Memory
8 MB Flash, 8 MB SDRAM (standard)
Print Width
4.09"/104 mm
Print Length
39"/991 mm
Print Speed
5"/127 mm per second
Media Sensors
Reflective and transmissive sensors
Media Characteristics
Media width
.75”/19.5 mm to 4.49”/114 mm
Media length
0.25”/6.5 mm to 39”/991 mm
Maximum media roll size
5”/127 mm O.D. on a 1.00”/25.4 mm, 1.5”/38 mm I.D.
core
Media thickness
0.003"/0.08 mm to 0.007"/0.18 mm
Media types
• Roll-fed or fan-fold
• Label stock (die cut or continuous, direct thermal or
thermal transfer)
• Tag stock (die cut
Zebra AFS GK420 Healthcare Labelling Desktop Printer
Zebra GK420 Healthcare Labelling Desktop Printer
GK420d Healthcare (direct thermal)GK420t Healthcare (thermal transfer)Standard Features
•
Print methods: thermal transfer or direct thermal
•
Programming language: EPL and ZPL are standard
•
Construction: dual-wall frame
•
Tool-less printhead and platen replacement
•
OpenACCESS™ for easy media loading
•
Quick and easy ribbon loading
•
Auto-calibration of media
•
Triple connectivity: USB, Parallel, Serial
•
ENERGY STAR® qualified
Printer Specifications Resolution 203 dpi/8 dots per mm MemoryStandard: 4 MB Flash; 8 MB SDRAM Print Width4.09”/104 mmMaximum Print Length39”/991 mmMaximum Print Speed5”/127 mm per second Media SensorsStandard: Fixed reflective and transmissive sensorsMedia CharacteristicsLabel and Liner Length
•
Maximum non-continuous: 39”/991 mm
•
Minimum label length: .38"/9.7 mm
Maximum Label and Liner Width0.75”/19 mm to 4.25”/108 mmMaximum Media Roll Size 5”/127 mm O.D.Media Thickness 0.003”/0.08 mm to 0.0075”/0.19 mmMedia Types Roll-fed or fan-fed, die-cut or continuous direct thermal labels with or without black line, tag stock, continuous receipt paper, wristbandsRibbon Characteristics
•
Outside diameter: 1.36”/35 mm
•
Standard length: 244’/74 m
•
Ratio: 1:1 media to roll to ribbon
•
Width: 1.33”/33.8 mm to 4.3”/109.2 mm
Zebra AFS HC100 Wristband Printer
Zebra HC100 Wristband
Healthcare Printer
HC100
Standard Features
•
Quick & easy wristband cartridge loading
•
Automatic print speed setting—up to
4 ips depending on installed cartridge
•
Direct thermal printing of barcodes, text
and graphics
•
Dual-wall frame, impact-resistant plastic
•
ZPL® or ZPL II® programming language
•
32 bit RISC processor
•
8 MB (2 MB user-available) Flash
memory (standard)
•
16 MB (4 MB user-available) SDRAM
memory (standard)
•
Element Energy Equalizer™ (E3™) for superior print quality
•
Dual communications interface: serial and USB
•
Odometer for print-length tracking
•
Illuminated media low/media out indicator
•
Tool-less printhead and platen replacement
•
Unicode™-compliant for multi-language printing
•
Instant media calibration—no wasted media
•
16 resident expandable bitmap fonts
•
One resident scalable font
•
Head-up sensor
•
Standard tear-off mode feature
•
XML-enabled printing—allows XML communications from information systems
•
ENERGY STAR® qualified
Printer SpecificationsMaximum Print Length
•
22"/558 mm
Minimum Print Length
•
3"/76 mm
Print Widths
•
0.75"/19.05 mm, 1"/25.4 mm, 1.1875"/30.16 mm
Resolution
•
300 dpi/12 dots per mm
Maximum Print Speed
•
2"/51 mm per second (Healthcare)
•
4"/102 mm per second (Z-Band Fun
& Z-Band Splash)
Media Characteristics Zebra offers a comprehensive range of wristband solutions for healthcare and hospitality
Zebra AFS ZT220 Industrial
Zebra ZT220 Industrial
Label Printer
Standard Features
•
Print methods: direct-thermal or thermal-
transfer (optional)
•
Construction: metal frame with choice of metal (ZT230) or plastic (ZT220) media cover
•
Bi-fold media door with large clear window
•
Side-loading supplies path for simplified media and ribbon loading
•
Element Energy Equalizer™ (E3™) for superior print quality
•
Bi-color LEDs for quick printer status
•
Icon-based LCD multilingual graphical user interface and full function keypad (ZT230)
•
Simple keypad (ZT220)
•
USB 2.0 and RS-232 Serial ports
•
ENERGY STAR qualified
Printer Specifications
Resolution
•
203 dpi/8 dots per mm
•
300 dpi/12 dots per mm (optional)
Memory
•
128 MB SDRAM memory
•
128 MB on-board linear Flash memory
Maximum Print Width
4.09”/104 mm
Maximum Print Speed
6”/152 mm per second
Media Sensors
Transmissive and reflective sensors
Media Characteristics
•
Maximum label and liner width: 4.5”/114 mm
•
Maximum non-continuous label length:
39”/991 mm
Media Width
0.75”/19.4 mm to 4.50”/114 mm
Print Length
•
203dpi: 157”/3,988 mm
•
300dpi: 73”/1,854 mm
Maximum Media Roll Size
•
8.0”/203 mm O.D on a 3.0”/76 mm I.D. core
•
6.0”/152 mm O.D. on a 1.0”/25 mm I.D. core
Media Thickness
0.003”/0.076 mm to 0.010”/0.25 mm

TSC Labelling Printers

TSC AFS TC Series Barcode Desktop Labelling Printer
TSC TDP-247 & TDP-345 Desktop Label Printers
Key Features •High quality double-walled clamshell design
•203 dpi and 300 dpi resolution models
•Direct thermal print technology
•Up to 177.8 mm (7") per second print speed
•Drop-in media loading
•Label capacity up to 214 mm (8.4") OD
•SD Flash memory expansion up to 4 GB
•Head-up sensor
•USB 2.0, parallel and serial connectivity
•Optional internal Ethernet interface
•Optional cutter, standalone keyboard and peel-and-present assembly

Applications •Small office or home office mailings
•Product marking
•High resolution print and graphics applications
•File-folder labeling
•Retail point-of-sale
•Shelf labeling
•Healthcare specimen labeling
•Inventory and asset management
•Shipping
TSC ME240 Series Thermal transfer Industrial Printer
Key Features •2-button 3-LED (basic model)/ 6-button LCD (advanced model) control panel
•Easily adjustable sensors
•Print head pressure adjustment knobs
•450 meter ribbon capacity
•Flexible firmware structure allows the printer to emulate popular printer languages
•Available in 203 dpi and 300 dpi resolutions
•Up to 4 Gigabyte Flash memory expansion using SD Flash memory
•Fast label throughput

Applications •Warehousing / Distribution •Labeling for •Packing
•Shipping
•Inventory Management

•Shelf/ Rack labeling

•Manufacturing •Work in process labeling
•Product Marking
•Inventory Management

•Compliance Labeling
•Healthcare •Patient ID
•Pharmacy unit dose
•Specimen labels
•Wristband printing
•Admissions
Heathcare TSC TDP 225 Series Barcode Desktop Labelling Printer
Heathcare TSC TDP 225 Series Barcode Desktop Labelling Printer
Key Features •Healthcare Patient Tracking
•Lab Sample Tracking
•Information Labels
•Medical Record Labeling
•Jewelry identification and pricing
•Work-in-Process Tracking
•Dietary Labeling
•Price Labeling
•Inventory & Asset Management
•Small Office or Home Office Mailing
•Shipping
•File-Folder Labeling
•Shipping
•File-Folder Labeling

Applications •High quality double-walled clamshell design
•127 mm 5” OD media capacity
•Up to 127 mm (5") per second print speed
•Available in 203 dpi and 300 dpi resolutions
•Easy media loading
•Head open sensor
•microSD Flash memory expansion up to 4 GB
•Serial and USB 2.0 connectivity
•Optional front LCD display, internal Ethernet, peel-off module, cutter module, Bluetooth module, external 802.11 b/g/n wireless module, stand-alone keyboard
•Optional front LCD display, internal Ethernet, peel-off module, cutter module, Bluetooth module, external 802.11 b/g/n wireless module, stand-alone keyboard
TSC AFS Alpha 3R Portable Labelling Printer
TSC Alpha 3R Portable Labelling Printer
Key Features •TSC Designed & Manufactured
•IP54-rated protective case to resist dust and water
•Plastic design with rubber over-mold construction that withstands 5 ft. (1.5 m) drop
•Wired & wireless communication interfaces: USB 2.0, RS-232, Bluetooth, and 802.11 b/g/n
•High capacity 2500 mAh rechargeable Lithium Ion batteries
•Large Paper capacity to reduce the frequency of changing paper roll
•High-speed processor and extensive memory for fast print speeds of up to 4" (102 mm) per second
•Last more than 12 hours of printing receipts on a single battery charge
•Supports TSPL-EZ (EPL2 and ZPL emulations) plus CPCL emulation
•2-Year Warranty is longer than other competitor’s warranty

Applications •Direct Store Deliveries (DSD)
•Field Repair/Installation
•Mobile Point-of-Sale
•Parking Citations
•Mobile ticketing
•Onboard Transportation Ticketing
•Utility Billing/Meter Reading

Selection of Labelling Printers

Intermec PC43d Desktop Printer light-duty labelling
Intermec PC43d Desktop Printer light-duty labelling
Super easy to install and use, the compact PC43d / PC43t is a purpose-built platform with an innovative design guided from customer input. This 4" wide desktop printer is perfect for space-constrained settings, and offers tailored solutions for transportation / courier, healthcare, and retail and hospitality markets, as well as small and medium business manufacturing, and warehouse and office environments.


Available in 4" direct thermal (PC43d) or 4" thermal transfer (PC43t), the Intermec PC43d / PC43t is designed to set a new standard in user friendliness and flexibility. PC43d / PC43t features a multi-language LCD or Icon-graphics user interface for maximum ease of use. User-installable connectivity options and accessories ensure that PC43d / PC43t will fit your business needs both today and tomorrow. Its low cost and fast operation make the PC43d / PC43t the smart choice for light-duty labelling applications where users need a reliable, easy-to-use printing solution.
Datamax O'Neil Workstation w1110 Label Printer
Datamax O'Neil Workstation w1110 Label Printer
The Workstation Series is the newest generation of desktop printers from Datamax-O'Neil. The w1110 compact desktop printer offers an industry leading design and standard features found on the company's Performance Series printer line, including Ethernet 10/100, 50 resident/scalable fonts, 300dpi printhead for superior print quality and industry standard PCL5e language. The compact design provides reliability and durability for environments requiring a small footprint for the most efficient output.

The Workstation Series are designed for a wide variety of industries and applications that require a small yet powerful printing solution. The Workstation Series' superior print quality is ideal for applications such as pharmaceutical, product labeling, asset management and shelf labeling. The compact thermal printers can dramatically reduce costs by streamlining operations, increasing productivity and managing your important assets.
Toshiba AFS B-FV4D
Toshiba AFS B-FV4D
Desktop Label Printer
Robust and compact, the Toshiba B-FV4D offers the best value in affordable, powerful label printing solution. It is a rugged and powerful label desktop printer which is compatible with all barcode printer control languages on the market. No matter you are looking for a label printing solution to integrate into your existing systems or replace aging operation units, B-FV4T is ideal for seamlessly fitting in, whatever the specification or printing requirement. A Direct Thermal printer (DT), the B-FV4D is available as 203 or 300dpi print resolution.
Honeywell AFS PC42t  Label Printer
Honeywell AFS PC42t
Desktop Label Printer
Direct thermal & thermal transfer light-duty label printer
The New PC42t. Everything you need to get it done, nothing you don’t.

How do we do streamlined? Strip away the distractions. Leave behind all the flash, fluff, and flourish. Streamlined is everything you need to do the job, nothing you don’t.

It’s straightforward, focused, economical – the embodiment of efficiency. And when it means making the labelling part of your job fast, easy, and on demand: It’s the new PC42t Desktop Printer

Easy to install and ready to print quickly, the streamlined PC42t thermal transfer desktop printer is an economical choice for media up to 110 mm (4.3 in) wide. Able to accommodate large ribbon sizes, the PC42t can print longer before needing media replenishment—lifting productivity in label-making operations.
•Great Value. The PC42t is an economical solution for light-duty thermal printing applications.
•Flexible Media Support. Supports a wide range of media, including 12.7 mm (0.5 in) or 25.4 mm (1 in) ribbon cores (depending on the model).
•Well Connected. Industry-standard connectivity includes USB host and device, and options for Ethernet, parallel and serial communications.
•Simple to Reload and Maintain. Easy to use, with a quick-opening design for media replenishment.
•Wide Printer Language Compatibility. Supports ESim (EPL), ZSim (ZPL-II) and Direct Protocol (DP) print languages for maximum compatibility.
